Clamping SG7-10-C
- Unit Price:US$13.29~US$37.79
- MOQ: no request
- Lead Time:7~15days
- Application:Used for CNC machine and servo motor
- Features:
- Coupling assembled by pressing a polyurethane sleeve into hubs on both sides.
- Can absorb vibration, parallel, angular misalignment and shaft end-play.
- Oil resistance and electrical insulation.
- Identical clockwise and anticlockwise rotational characteristics.
- Two different hardness sleeves are available.
- Fixing type of clamping screws.
- Material:
- Aluminum Alloy, PTU
- Finish:
- Black Anodizing
- Remark:
- The moment of inertia and the quality is calculated according to the maximum shaft hole
- Bore dimensions can be customized
- It can be customized with additional keyway
