Clamping SG7-8
- Unit Price:US$4~US$26.86
- MOQ: no request
- Lead Time:7~15days
- Application:Used for transmitting power in kinds of mechanical equipment such as blower fan
- Features:
- Excellent response and high torque capacity.
- Zero backlash.
- Identical clockwise and anticlockwise rotational characteristics.
- Stainless steel plate springs absorb parallel, angular misalignment and shaft end-play.
- Clamping type.
- Material:
- Aluminum Alloy, Stainless Steel Diaphragm
- Finish:
- Silver Anodizing
- Remark:
- The moment of inertia and the quality is calculated according to the maximum shaft hole
- Bore dimensions can be customized
- It can be customized with additional keyway
